上海江南制药机械有限公司的智能盐雾机精巧如诗传统的喷雾技术创新而又高效

上海江南制药机械有限公司智能盐雾机之简介，乃专为各类材料表面处理而设计，涵盖五金电镀、电子零部件、化工涂料、汽车等行业的质量检测，以检验其耐蚀性。内外箱尺寸分别为600×450×400mm和1070×600×1180mm。

一.技术参数：

1.温度范围：室温+10℃~55℃

2.湿度范围：≥93%R.H

3.温度均匀度：±2℃

4.温度波动度：±0.5℃

5.雾沉降量：1～2ml/80c㎡

6.喷雾方式：连续/周期任选

7试验方法：

中性盐雾试验(NSS试验)

醋酸盐雾试验(ASS试验)

盐雾试验(SS试验)

铜加速醋酸盐雾試驗(CASS試驗)等

试样架可满足15℃~30℃倾斜試驗（两层）

9空气压缩机型号为V-0.013/12.5，排气压力为1.25Mpa，容积流量为0.13m³/min（客户自配）。

二.Box体制作材料：

1.PVC增强硬质塑胶板，不仅耐老化、耐腐蚀，还能抵抗时间导致的表面退色纤维化。

2.Air-tight透明进口耐冲击板材制造，便于观测测试过程。

三.Additional Details:

3.Additional Details: Box body heat system uses water jacketed heating, with a titanium alloy protective tube and an embedded nickel-chromium alloy far infrared heating core for quick heating and uniform temperature distribution.

四.Executive Standards:

This product meets GB2423,17《Electrical and Electronic Products Basic Rules Test Ka》, Salt Mist Corrosion Test Method; GB10587, GJB150, DIN50021 Continuous Salt Fog Test; International Standards; our company's test chamber has passed the detection of the National Environmental Testing Equipment Detection Center.

Five Standard Accessories:

Number Name Quantity

1 ∨ Type Rack 4

2 ○ Type Rod 6

3 Standard Measuring Cylinder 1

4 Temperature Indication Needle 2

5 Filter (Please replace regularly) 1

6 Fog Collection Device (80cm²) 1

Three Random Materials and Accessories:

Random Material List:

Number Description Quantity Unit Price Total Price (Yuan)

Product Code: SPM001
